DEYE 5KW 5000W MPPT INDY 5000 Single Phase Solar Hybrid Inverter With LCD Display

DEYE 5KW 5000W MPPT Single Phase

-Self- consumption  and feed-in to the grid

-Auto restart while AC is recovering

-Programmable supply priority for battery or grid

-Programmable multiple operation modes: on grid ,off grid  and UPS

-Configurable battery charging current /voltage based on applications by LCD setting

-Configurable  AC/Solar/Generator Charger priority by LCD setting

-Compatible with mains voltage or generator power

-Overload/over temperature/short circuit protection

-Smart battery charger design for optimized battery performance

-With limit function ,prevent excess power overflow to the grid

-Supporting  WIFI monitoring and built-in 2 strings of MPP trackers

-Smart settable three stages MPPT charging for optimized battery performance

-Time of use function

-Smart Load function

Product Overview

1. Inverter  Indicators

2.LCD display

3.Function buttons

4. Battery input connectors

5.BMs 485 Port

6. BMS CAN Port

7. DRMs Port

8.Parallel Port

9.Function Port

10.RS 485 Port

11.Generator input

12.Load

13.Grid

14.Power on/off button

15.DC switch

16.Pv input with two MPPT

17.Battery

18.Temperature sensor

19. WIFI

20.Fan (Note :for some hardware version, it doesn’t have this fan)

Package Dimension:

880 x 600 x 860mm

Package includes:

1 x DEYE 5KW 5000W MPPT Single Phase
