Fivestar- PD1248-3P 12Kw 48V 3Phase Powerful Hybrid Inverter

Fivestar- PD1248-3P 12Kw 48V 3Phase Powerful Hybrid Inverter

Product Features

• 230v/400v Three Phase Pure Sine Wave Inverter.
• Self-Consumption And Feed-in to The Grid.
• Auto Restart While AC is Recovering.
• Programmable Supply Priority For Battery Or Grid.
• Programmable Multiple Operation Modes: On Grid, Off Grid and UPS.
• Configurable Battery Charging Current/Voltage Based On Application by LCD Setting.
• Configurable AC/Solar/Generator Charger Priority by LCD Setting.
• Compatible With  Mains Voltage Generator Power.
• Overload/Over Temperature/Short Circuit Protection.
• Smart Battery Charger Designed For Optimized Battery Performance.
• With Remit Function, Prevent Excess Power Overflow To The Grid.
• Supporting WIFI Monitoring And Build-in 2 Strings For 1 MPPT Tracker, 1 String for 1 MPPT Tracker.
• Smart Settable Three Stages MPPT Charging For Optimized Battery Performance.
• Time To Use Function.
• Smart Load Function.

Model; FS-I008 12KVA PD1248-3P

Product Type– Hybrid Inverter

Enclosure– IP65

Ambient Temperature– 40-60 Degrees (<45 degrees caseous derating)

Protection Level– Class I

AC Input/Output Data

Normal Input/Output Power– 13200W/12000W

Max. Apparent Power– 13200VA

Normal Voltage– 3W/N/PE230/400Vac

Max. Input/Output Current– 35A/17.4A

AC Frequency– 50/60Hz

AC Output Power Factor– 0.8 leading to 0.8 lagging

Stand Alone Data

Normal AC Output Power– 12000W

Normal AC Output Voltage– 230/400Vac

Max. Output Current– 17.4A

Normal AC Output Frequency– 50/60Hz

PV Input Data

PV Input Voltage– 550Vdc(160-800vdc)

MPPT Input Range– 200-650Vdc

Max. Input Current– 34Adc+17Adc

PV Input Current– 26Adc+13Adc

Max. PV Input Power– 15600W

Battery Data

Battery Voltage Range– 48Vdc(40-60Vdc)

Max. Charging and Discharging Current– 100/240Adc Max

Type of Battery– Lithium/Lead-acid

Warranty

2 Year Repair Warranty
All Inverters And Batteries Must Be Installed By a Qualified Electrical Wireman or Master Electrician With a Valid Registration With The Department of Labour. A valid Electrical Certificate Of Compliance (COC) Must Be Issued Once Installed, Specific To The Installation Of The Backup or Solar System. Any Warranty Claim Submitted Without Installation Photos, a Valid COC And Proof Of a Qualified wireman/Master Electrician Installing The Unit, Can Be Rejected And Will Render The Warranty Claim Null At Void.

Package

Inverter Dimension- 68 x 44 x 26cm

Box Dimension- 81 x 56 x 39cm

Inverter Weight- 37.5Kg

Box Weight- 43.5Kg

Inside the Box

1 x 12kw 48v 3phase Hybrid Inverter

1 x Wall Mount Bracket

1 x WI-FI-Plug(optional)

1 x Parallel Communication Cable

1 x Temperature Sensor

3 x Sensor Clamp

4 x Stainless steel Anti-Collision Bolt M8x80

DC+/DC- Plug Connectors Including Metal Terminal xN

1 x Manual Book

1 x L-type Hexagon Wrench
